Best Large EPS C and C Engraving Machine at Competitive Price in Malta, Spain
☆The machine uses top-quality four-row imported ball bearing, wide linear lead rail, and self-lubricating block. So it can balance the force in all directions to ensure the machine’s accuracy and strength when engraving.
CNC Router Machines Video
features
- It has the very large working table of 3000*50000mm.
- The 4th axis can rotate ±90 degrees to realize 3d engraving.
- Equipped with many high-end components like Taiwan SYNTEC control system, Taiwan TBI ball screw, Shimpo reducer, etc.
Parameters
| Description | ELE-3050 | |
| Working size | 3000*5000*1000mm | |
| The 4th axis | ±90° | |
| Transmission | X /Y rack and pinion drive Z Taiwan TBI ball screw | |
| Table structure | Cast steel structure | |
| Spindle power | Italy 9kw HSD ATC air cooling spindle | |
| Spindle speed | 24000rpm | |
| Working speed | 20m/min | |
| Motor driver | 850w YASKAWA servo,1 kw YASKAWA servo driver | |
| Inverter | 11kw Taiwan Delta Inverter | |
| collet | BT40 | |
| Computer Interface | Ethernet | |
| Flash Memory | 256M(with CF card) | |
| Table Surface | Milling steel table(T-slot) | |
| Control System | Taiwan SYNTEC | |
| PS. All the working size and specifications can be customized according to your requests | ||
Application
Casting mold industry: It can be used for the precision production of various cast wood molds for various automobiles, ships, aviation, trains, etc. And also be used for research and development and production of automotive interior decoration and exhibition decoration materials.
Casting and sculpture industry: Processing and engraving of various casting process products, lost foam, exhibition decoration materials, and GRG decoration materials. Building decoration industry: Processing and production of building decoration materials such as GRG and GRC.
