Great 4-Spindle CNC Stone Engraving Machine for Sale in Estonia, Bermuda

☆This multi-spindle stone CNC machine has a variety of machining functions. For instance, it can cut and engrave a variety of work pieces at the same time, which greatly improves the production efficiency. It is very suitable for mass production processing with low budget.

Stone Engraving Machines Video

Parameters

Model ELECNC1815-4S Stone CNC Router
X,Y axis travel 1800x1500mm, option: 1500*3000mm; 2000*3000mm; 2000*4000mm, etc
Z axis travel 200mm, option: 300mm, 400mm, 500mm, etc
Spindle type 3kw water cooling spindle, 24000RPM
4.5kw/ 5.5kw/ 6kw for optional
Inverter type 3.7kw Fuling inverter
Control system Mach3 controller
Driving system Stepper motors and drivers
Machine structure Professional stone cnc bed, with heavy duty body more thicker and stronger
Work table slot working table, with steel water sink; Stainless steel sink for optional
Linear guide Taiwan linear guide 20#
Transmission X,Y axis: Germany Helical Rack and Pinion
Z axis: Taiwan TBI high precision ball screw
Dust cover Dust covers for X, Y axis,  protect the rails
Cooling system Water cooling
Lubrication system Automatic lubrication system
Tool calibration Manual tool sensor calibration
Cables Germany Igus cables with CE, cUL certificate
Compatible software Artcam, Alphcam,Type 3, Ucancam, Aspire, etc
Command language G Code
Traveling speed 25m/min
Working speed 0-20m/min
Re-positioning accuracy ±0.05mm
Working accuracy ±0.05mm
Working air pressure 0.6MPa
Working voltage 220V 1PH/3PH 50HZ/60HZ
380V 3PH 50HZ/ 60HZ

Application

Stone engraving machine is mainly designed to deal with stone work such as line carving, 2D plane carving, 3D relief carving, shadow carving, cutting, drilling. It can process marble, granite, jade, crystal, tombstone, agate, ceramic, glass, plastic, chemical composite board, bamboo, wood, curved surface, spherical surface, stainless steel, iron, copper, aluminum, titanium alloy and other materials. If you have the above materials need to process, stone engraving machine is definitely your best choice.

Production Facility

Blue Elephant CNC Factory View
Blue Elephant CNC Router Machine Factory View

Quality Control & Testing

CNC Machine Quality Control Detail Image
CNC Machine Quality Control Images

Get Price & Details
